TURBO SERIES SELF-CONTAINED AIR CONDITIONING

Self-contained Air Conditioner from 6000 BTU/h to 16000 BTU/h

  • Available in 230V 50Hz, 230V 60Hz, 115V 60Hz
  • Up to 21 % increased cooling capacity and up to 27 % more energy efficient
  • Designed from the inside out with multiple patented innovations
  • Compact design uses less space
  • Vibration-isolation mounts reduce noise and vibration
  • Rust-free composite drain pan
  • Engineered to maximize the performance of R-410A refrigerant
MCGX MODULAR TITANIUM CHILLERS

Modular Titanium Chiller from 24000 BTU/h or 180000 BTU/h

  • Available in 230V 50 Hz, 230V 60Hz, 400V 50Hz 3PH, 400V 60 Hz 3 PH
  • Titanium condenser dramatically increases product lifespan
  • Up to six modules can be staged
  • Hermetically sealed and pre-charged with R-410A refrigerant
  • Features freeze controls, high-limit switches, high and low aquastats and timers
  • Unaffected by vibration, moisture or ambient temperatures up to 140 °F/60 °C
  • Monitored and protected by Dometic’s exclusive Digital Diagnostic Controller (DDC)
EMERALD SERIES SPLIT GAS AIR CONDITIONING - CONDENSING UNITS

CONDENSING UNIT FROM 6000 BTU/H TO 72000 BTU/H

This condenser has reversing valve, pressure switches, and service ports centrally located for easy maintenance access from any side. Vibration-isolating compressor mounting system reduces noise and vibration. Pair this with a Dometic Emerald TurboVap R-410A evaporator.
TVE SERIES SPLIT GAS AIR CONDITIONING - EVAPORATING UNITS

DOMETIC TVE

Evaporating Unit from 4000 BTU/h to 16000 BTU/h

  • Available in 115V or 230V (50/60Hz)
  • Rust-free composite drain pan has anti-slosh, “positive flow” drain channels for no spills and rapid removal of condensate
  • Designed to be used with Emerald Series R-410A condensers
  • Vibration-isolation mounts reduce noise and vibration
  • Single adjustment screw for 270° of blower rotation
TWCX SERIES MODULAR TITANIUM CHILLERS

DOMETIC TWCX

Modular Titanium Chiller from 24000 BTU/h to 72000 BTU/h

  • Available in 230V 50Hz, 230V 60 Hz, 400V 50Hz, 400V 60 Hz 3PH
  • With DDC – Digital Diagnostic Control
  • Titanium condenser resists erosion and corrosion
  • Reverse-cycle unit cools and heats
  • Can be multiplexed for larger capacity
  • Includes flow switch, high- and low pressure switches, and inlet and outlet circulated water temperature sensors
  • Compact, enclosed design. High-efficiency rotary or scroll compressors
VARC SERIES CHILLED WATER AIR CONDITIONING

DOMETIC VARC

Variable Capacity Chiller from 12000 BTU/h to 72000 BTU/h

  • Available in 230V 50HZ, 230V 60HZ
  • Variable capacity from 12000 BTU/h to 72000 BTU/h
  • Operates steadily at lower speeds to provide maximum efficiency
  • Electronic expansion valve for precise control of superheat
  • Select from three user-adjustable amp limits: Econo, Standard, or Boost
  • Compact footprint
  • Easy, flexible plumbing configurations with less depth needed
MCS T6 SERIES POWERFUL, QUIET & COMPACT

DOMETIC MCS T6

Marine climate system, 6000 BTU/h, 1130 W

  • Cooling capacity 6000 BTU/h; heating capacity 1750 W
  • Consumption (at 230 V): 890 W/1130 W
  • Reliable comfort thanks to versatile functions: heat, cool and dehumidify
  • Designed for fast, easy retrofitting
  • Made from high quality corrosion-resistant materials
  • All installation components included
  • Ultra compact design for neat, unobtrusive fit
MCS T12 SERIES POWERFUL, QUIET & COMPACT

DOMETIC MCS T12

Marine climate system, 12000 BTU/h, 3500 W

  • Cooling capacity 12 000 BTU/h; heating capacity 3500 W
  • Consumption (at 230 V): 1030 W/1270 W
  • Reliable comfort thanks to versatile functions: heat, cool and dehumidify
  • Designed for fast, easy retrofitting
  • Made from high quality corrosion-resistant materials
  • All installation components included
  • Ultra compact design for neat, unobtrusive fit
MCS T16 SERIES POWERFUL, QUIET & COMPACT

DOMETIC MCS T16

Marine climate system, 16000 BTU/h, 4700 W

  • Cooling capacity 16 000 BTU/h; heating capacity 4700 W
  • Consumption (at 230 V): 1320 W/1660 W
  • Reliable comfort thanks to versatile functions: heat, cool and dehumidify
  • Designed for fast, easy retrofitting
  • Made from high quality corrosion-resistant materials
  • All installation components included
  • Ultra compact design for neat, unobtrusive fit
DOMETIC MCS-DSPL Elite II display for Dometic marine climate systems

DOMETIC MCS-DSPL

Elite II display for Dometic marine climate systems

  • Easy to use with raised buttons and scroll button for mode selection
  • Cool-only, heat-only, dehumidify and automatic mode.
  • Automatic humidity control reduces moisture when the boat is unattended.
